Features Overview
Technical Specifications
Features Overview
- Ethernet & Wi-Fi Standard Feature on All Devices
- User-Friendly UI and Menu Design
- Hardware-Level Clock Data Input Authentication
- User Level Duplicate Punch Prevention
- Multiple Level Job Code Entry Support
- Enhanced Network Security
- Automatic Status Key Switch
- Supports up to 9 Digit User ID
- Daylight Savings Time Support
- Built-In Contact Relay for opening doors or ringing bells
- USB HOST port for easy data transfer to a USB flash drive
- Highly durable and reliable magnetic reader
- Rugged 20 key keypad w/ four programmable function keys
- Multi Factor authentication options using Card/PIN or Password
- Large Color Display
- Audio and Visual feedback for accepted and rejected card swipes
- Mounting plate included
Technical Specifications
| Reader / Input | Badge (RFID Proximity 125Khz) |
| Reader / Input | Keypad |
| Communication | Wi-Fi & Ethernet |
| Communication | Ethernet POE (Power Over Ethernet) – Optional |
| Function | Configurable Functions |
| Function | Relay (Bell / Schedules) |
| Function | Auto Daylight Savings Adjustment |
| Function | Relay (Door / Transactional) |
Capacity
ID Cards: up to 10,000
Transactions: up to 100,000
Display
3.0 in. TFT Color Screen
Communications
Ethernet, USB-Host, Wi-Fi
Power
12 V DC, 1.5 A
Optional: 12V POE injector (sold separately)
Optional: 12V Battery Backup (sold separately)
Environment
Operating Temperature: 32º F to 113º F (0° C to 45° C)
Operating Humidity: 5% to 80%
Dimensions
Width: 6.5 in. (16.5 cm)
Height: 5.5 in. (14 cm)
Depth: 1.8 in. (4.6 cm)
Weight: 0.95 lbs. (0.43 kg)
